Supports on/off-grid AC coupling, three-phase and multi-machine parallel operation, intelligent load management (customized), and BMS remote upgrade (customized).
Product Highlights
Safe and Reliable
Passed ENIEC 61000-6-1:2019, EN IEC 61000-6-3:2021; EN 62109-1:2010; EN 62109-2:2011 test certification.
Friendly and Flexible
Support multi-machine parallel connection. Compatible with a variety of battery connections such as lead-acid and lithium-ion batteries.
Intelligent and friendly
Support intelligent load management (customized),Support BMS remote upgrade function (customized).
Choose our benefits
Reduce the use of fossil fuels and be more environmentally friendly
Reduce the use of fossil fuels and be more environmentally friendly
Continuous, stable, and reliable power supply
PV expansion will be more convenient in the future
Model
R6KH3-P
R8KH3-P
R10KH3-P
R12KH3-P
R15KH3-P
PV input data
Max. PV input power (kW)
22.5
9
12
15
18
Max. PV input voltage (V)
1,000
Min. PV input voltage (V)
125
Start-up voltage (V)
125
MPPT voltage range (V)
180~850
MPPT voltage range@full-load (V)
250~850
Rated PV input voltage (V)
600
No. of MPPT trackers
2
No. of strings per MPPT tracker
1/1
2/2
No. of strings per MPPT tracker
18/18
.
20/20
Max. short-circuit current per MPPT (A)
25/25
.
30/30
Battery input data
Battery type
Lithium-ion / Lead-acid
Max. charge / discharge power (kW)
6.6
8.8
11
13.2
16.5
Battery voltage range (V)
150~550
Battery voltage range@full-load (V)
180-550
230-550
285-550
340-550
425-550
Max. charging / discharging current (A)
50/50
Rated charge / discharge current (A)
40/40
Battery charging strategy
Self-adaption to BMS
BMS communication
CAN
AC output data (grid side)
Rated output power (kW)
6
8
10
12
15
Max. apparent output power (kVA)
6.6
8.8
11
13.2
16.5
Max. apparent input power(kVA)
13.2
17.6
22
26.4
33.3
Rated grid voltage (V)
220 / 380; 230 / 400
Grid voltage range (V)
187~264.5
Grid input voltage (V)
380; 400
Rated grid frequency (Hz)
50/60
Grid frequency range(Hz)
45-55 / 55-65
Rated output current (A)
8.7
11.5
14.4
17.3
21.7
Max. AC output current (A)
9.5
12.7
15.9
19.1
23.8
Power factor
>0.99 (0.8 leading ~ 0.8 lagging)
THDi
＜3%
Grid type
3L+N+PE
AC output data (back-up)
Rated output power (kW)
6
8
10
12
15
Max. apparent output power (kVA)
6.6
8.8
11.1
13.2
16.5
Rated output voltage (V)
220 / 380; 230 / 400
Rated output frequency (Hz)
50/60
Rated output current (A)
8.7
11.5
14.4
17.3
21.7
Max. AC output current (A)
9.5
12.7
15.9
19.1
23.8
Peak output power
≥110%, 10mins；≥120%, 1.25min；≥150%, 20ms
Back-up switch time (ms)
<10
THDu
<2%
PV input data
Supported protection
PV reverse polarity protection, Anti-islanding protection, Ground fault protection, Battery reverse protection,
Leakage current protection, Insulation resistance detection, Backup output short circuit protection,
AC under-voltage protection, AC output over-current protection, AC over-voltage protection
Over voltage category
DC Type II / AC Type III
Certifications and standards
Certificates
IEC 61000-6-1/-2/-3/-4, IEC 61000-3-11, IEC61000-3-12; EN 62109-1, EN 62109-2; EN50549-1;
EN50549-10; EN50438; G98/G99:2022; VDE-AR-N 4105:2018; CEI 0-21:2022; C10/11; Rfg:2016/NC Rfg:2018/PTPiREE:2021;
NRS 097-2-1:2017; Hungary; NTS V2.1:2021-07&UNE217002:2020&UNE217001:2020; NA/EEA-NE7 – CH 2020;
OVE Directive R 25:2020, TOR Erzeuger Type A V1.2; TR3.3.1:2019;ANRE228; ANRE228; NA/EEA-NE7;
PPDS:2022 for A1&A2; RS 097-2-1 :2017; OVE Directive R 25:2020, TOR Erzeuger Type A V1.2; EIFS 2018:2
